Floor plans provide a basic view of how a property is arranged. For off-plan projects, these drawings give buyers their first look at the layout before construction begins. Reading the JVC offplan projects plan correctly supports better planning and helps buyers set practical expectations about the unit.
Check the orientation and entry point:
Start by locating the entry door on the plan. This gives a reference for how rooms connect and where movement begins. Directional arrows or compass markers (N for north) show which way the apartment faces. Knowing the direction may influence lighting or temperature during the day.
Measure the room sizes:
Room dimensions are usually listed in metres or feet. Check both the length and width of each area, such as bedrooms, kitchens, and living rooms. These numbers show how large the spaces are and help compare units within the same building. Some floor plans include the total area, while others divide it into usable and built-up size.
Notice the wall thickness:
Lines on a floor plan show walls. Thick lines represent main walls, and thinner lines mark partition walls. This gives a rough sense of which walls are structural and which ones may be adjusted or not. Wall placement also affects how furniture fits inside the room.
Look for windows and doors:
Windows are usually shown as open lines along a wall, and doors appear as arcs or swinging lines. Note where each door opens and how much room it takes when opened. This helps in thinking through furniture layout or movement between rooms.
Identify fixed fixtures:
Some floor plans include symbols for fixed features like sinks, toilets, bathtubs, kitchen counters, or wardrobes. These markers show how plumbing and fittings are placed. This layout impacts how easily the unit may be customised later.
Understand shared and private areas:
In larger developments, some parts of the plan may include shared areas like hallways, lifts, and stairs. These are often shaded or marked differently from private spaces. Buyers should review which parts belong to the unit and which are shared with neighbours.
Compare with unit number and floor level:
Each unit in the building has a number and may be placed on a different level. Ensure the floor plan matches the correct unit and reflects the correct orientation based on its floor. This check helps avoid mix-ups during booking.
